8lienbike
PRODUCT DETAILS
| Wheel Size: | 700C |
| Outer Rim Width: | 34mm |
| Inner Rim Width: | 25mm |
| Rim Finish: |
Coating Free
|
| Optimized tire size: | 28mm-48mm |
| Minimum labeled tire size: | 28mm |
|
Tire Fit: |
Clincher and Tubeless Tires |
|
Tire Pressure: |
Clincher Tire: < 125 psi (8.6bar) | Tubeless Tire: < 90 psi (6.2bar) |
|
Rider Weight Limit:
|
100KG |
BUILD SPECS
| Hubs: | R01 Hub | Ratchet 36T | S&S Ceramic Bearings |
| Spokes: | Carbon Spoke(4.5mm) | 1:1 pattern |
| Spacing: | Front: 12x100 | Rear: 12x142 |
| Brake Type: | Disc Brake Centerlock (lockrings not included) |
DIMENSIONS
| Depth: |
L3W: Front: 30mm , Rear: 35mm L5W: Front: 45mm , Rear: 50mm L6W: Front: 60mm , Rear: 60mm |
| Internal Width: | 25mm |
| External Width | 34mm |
| Spoke Count | 20H/20H |
WEIGHT
|
L3W: 1170+/-30g L5W: 1240+/-30g L6W: 1270+/-30g |
 |
Ultra Toray Carbon Fiber T1000
For the new L serial wheels, we use Ultra Toray Carbon Fiber T1000.It takes weight saving and strength to an entirely new level. Light weight yet robust and stiff. |
 |
Reinforcement Layer-up
With our reinforcement carbon technology we increase the number of carbon layers only around the spoke holes on the inside of the rim. This way we significantly reduce its weight, while preserving the strength and stiffness. |
 |
Coating Free | Scratch Resistance
Paintless Rims come out of the molds as a finished product. Traditionally, rims are wet-sanded to remove imperfections like excess resin and then sprayed with a clear coat. Paintless rims come with a factory finish and the outer carbon layer is never disturbed after the curing cycle is completed which contributes to the hardest wearing and finish we have ever produced. |
 |
Tubeless Compatible Technology
The unique geometry of our Tubeless System ensures easy mounting, direct inflation, long-lasting pressure and compatibility with all (tubeless) tires. |
 |
Strict Quality Control System
1. Vertical Stiffness Test: 50kgf PASS 2. Lateral Stiffness Test: 40kgf 3. Vertical Impact Test: PASS (All test points pass 300kgf) 4. Spoke Holes Ultimate Strength Test: PASS (All test blocks pass 300kgf) 5.Tire Installation Test: Pass (Clincher tire 150psi) |
 |
S&S Ceramic Bearing R01 Hubs
Durable, sealed ceramic bearings and reliable engagement mechanisms contribute to smoother rolling and better power transfer. |
 |
Ratchet System
The Ratchet System with 36T provide a larger surface area for engagement compared to traditional pawl systems, which translates to improved durability and more efficient power transfer. The ratchet system also simplifies maintenance and reduces the number of parts, enhancing reliability and ease of service. |
 |
Ease of Maintenance
Our R01 hubs are designed with ease of maintenance in mind. The tool-free design of many models makes it straightforward to perform routine maintenance and servicing, which is a significant advantage for both amateur and professional cyclists. |
 |
Carbon Spoke Aero Design
The lightweight Carbon Aero spokes provide high lateral stiffness resulting in increased efficiency when accelerating and climbing. The optimized aerodynamic shape of the spoke reduces aerodynamic drag. |
$1,329.00
